23.8" Touch Self-Service Kiosk

..............................................................................................
Model : RSD238 Brand: RISENDA

HS Code : 847150000000

1. Metal Case+Toughened Glass
2. 10 point capacitive touch screen
3. 3G/4G/WIFI/BT/Speaker Optional
4. Card reader IC/NFC/RFID Optional
5. Android/Windows 10/11
6. Floor Standing/Wall Mounted
7. 24 Months Warranty
Availability:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

  • S600

  • RISENDA

  • 8470501000


WindowsAndroid
CPUIntel® Celeron® Processor J6412 1.5M Cache, up to 2.60 GHzRK3568 Cortex-A55 dual-core,up to 2.0GHz
Intel® Celeron® Processor 5205U 2M Cache, 1.90 GHz
Intel® Celeron® Processor J4125 4M Cache, up to 2.70 GHz
Intel® Core™ i3 Dual Core ( 3th,4th.5th.6th.7th.8th.10th,11th Gen)
Intel® Core™ i5 Dual Core ( 4th.5th.6th.7th.8th.10th,11th Gen)
Intel® Core™ i7 Dual Core ( 5th.6th.7th.8th.10th,11th Gen)
MemoryDDR3 (2GB,4GB,8GB), DDR4(4GB,8GB,16GB)DDR4 2GB,4GB,8GB
Hard Disk32GB,64GB,128GB,256GB,512GBEMMC 8GB,16GB
Ethernet100M/1000M Self-adaptionWiFi IEEE 802.11 b/g/n,10/100/1000M Adaptive Ethernet RJ45 connector+4-Pin POE header MiniPCI-E
OSWindows 10 /11Android 11.0
Display23.8" Industrial Grade A LED
Resolution1920 x 1080 Pixels
Brightness300 CD/㎡
Touch ScreenBezel-free 10-Ponits Capacitive Touchscreen
Housing MaterialAluminum Alloy
I/O PortsUSB x 6 ; RJ45 x 1 ; COM x 1:COM(RJ45) x2 ; VGA  1 ; Audio x 1; DC x 1 ; on-off Switch x 1
Power Supply100-260V  AC ( 50-60Hz) 12V 5A
PackingWooden box
CertificationCE/FCC/ROHS /CCC/ UL
Optional Built inWifi & BT & Speaker
ReaderNFC
Way to installWall mounted / Floor stand

Payment Kiosk

1


23.8" GENERAL SPECIFICATIONS

Screen Size :   23.8”   real diagonal

Driver Element :    a-si   TFT active matrix

Pixel Number  :   1920   x R.G.B. x 1080 pixel

Pixel Pitch :    0.2745   (H) x 0.2745 (V) mm -

Pixel Arrangement :    RGB   vertical stripe

Display Colors :    16.7M   color

Transmissive Mode :    Normally   black

Surface Treatment :    AG   type, 3H hard coating, Haze 25

Luminance, White :   300   cd/m2

Color Gamut :    72%   of NTSC(Typ.)

Power Consumption:     Total   20.922W (Max.) @cell 4.29W (Max.), BL 16.632W(Max.)

Physical Specification

Surface :   anti-scratched tempered glass

Power supply :   AC 110–240, 50-60Hz

Operating temperature  :  0°C ~ +40°C

Storage temperature :   -20°C ~ +60°C

Humidity  :  0% ~ 80%

Printers  : ticket printers

Scanners    QR code / Barcode scanner

peripheral   (Optional)    Wifi / NFC
